Ballooned memory has triggered inside the Guest OS of the VM due to misconfigured Resource Pool settings
search cancel

Ballooned memory has triggered inside the Guest OS of the VM due to misconfigured Resource Pool settings

book

Article ID: 419240

calendar_today

Updated On:

Products

VMware vCenter Server

Issue/Introduction

  • The affected VM triggered the "VM memory usage" alarm due to an abrupt and spiking memory utilization.
  • The Memory Utilization percentage within the VM's Guest Operating System may show peak values that are higher than the actual utilization.
  • Upon validating performance charts for Ballooned memory values by navigating the below path, it may show a high Ballooned memory value.

    VM > Monitor > Performance > Advanced > View > Memory     and review the value for Ballooned memory



  • The VM's memory utilization may show a peak of, or nearly, 100% though the underlying host or cluster reports resources to be available.
  • A vMotion or power cycle of the VM may provide only temporary relief while the issue is likely to re-manifest within a short period.

Environment

vSphere

Cause

This issue is triggered due to Incorrect settings such as Reservation, Limit, or Shares at the VM or Resource Pool level.

Resolution

Step 1: Identify the settings at Resource Pool level

  1. Navigate to the affected Resource Pool in the vSphere Client.

  2. Go to Resource Pool -> Actions - > Edit Resource Settings and validate below highlighted settings.



  3. Review the Limit field. If it is set to a specific value other than "Unlimited", this is the cause.

  4. Review the Reservation field. Ensure the Reservation is not constraining the pool's resources.



Step 2: Identify the settings at Virtual Machine level

After correcting the Resource Pool settings, check the individual VMs that are show casing Ballooned Memory value

  1. Right-click the affected VM > Edit Settings.

  2. Navigate to VM Options > Resources > Memory.

  3. Ensure the Limit, Reservation and Shares values on the individual VM is set to Unlimited.



Additional Information

https://techdocs.broadcom.com/us/en/vmware-cis/vsphere/vsphere-sdks-tools/8-0/web-services-sdk-programming-guide/resource-management/creating-and-configuring-resource-pools/configuring-reservation-and-limit-for-resource-pools.html
