Issue/Introduction

We are excited to announce the upcoming arrival of VMware VeloCloud SD-WAN Edge models 710-5G, 720 and 740, the latest additions to the VMware VeloCloud SD-WAN.

This document lists the details about

• SD-WAN Edge Model 710-5G ports
• Supported software.
• Activation steps

For detailed information about the product please refer below link,

https://blogs.vmware.com/sase/2024/08/27/vmware-velocloud-sd-wan-edge-710-5g-720-740/

Cause

N/A

Resolution

SD-WAN Edge Model 710-5G

• Designed for entry-level branch networks, the Edge 710-5G greatly enhances deployment flexibility, supporting cellular connectivity in scenarios such as retail stores, ATMs, or remote branch deployments.
• With zero-touch provisioning (ZTP), the device activation process is rapid and effortless.
• This model supports dual physical SIMs for 5G/LTE and includes SIM failover, which automatically switches to an alternate circuit if coverage is diminished or lost.
• It is also backward compatible with 3G and 4G. Furthermore, the embedded eSIM unlocks transformative opportunities in scalability, provisioning, management, and deployment.

SD-WAN Edge Model 710-5G ports:

GE1 to GE4, SFP port, dual physical SIMs , Console and USB port.

Supported software.

From Release 5.2.4 includes support for VeloCloud Edge models 710-5G, 720, and 740.

https://docs.vmware.com/en/VMware-SASE/5.2.4/rn/vmware-sase-524-release-notes/index.html

Activation steps

Step 1. Connect to Power

Step 2. Connect to the Internet  (Connect one of the default WAN ports (GE3, GE4, or SFP) to an available
internet connection)

Step 3. Follow Email Instructions

Step 4. Connect Local Devices Connect local devices via the LAN ports (GE1 or GE2) or through the Edge’s Wi-Fi
accordingly

Above steps are provided for basic information on LAN and WAN ports used in SD-WAN Edge Model 710-5G ports

For detailed steps to activate the edge please refer below link

SD-WAN Edge Model 710-5G Activation

After following the instructions, if you are still unable to activate the SD-WAN Edge 710, contact your reseller first.

For VMware SD-WAN support ,For VMware SD-WAN support

Additional Information

Refer below link for VMware SD-WAN Supported SFP Module List

VMware SD-WAN Supported SFP Module List
