Site Recovery Plug-in displays "Unknown error. The latest version of Site Recovery UI is not available. Some functionality might be limited" on the SRM appliance

Products

• VMware Live Recovery

Issue/Introduction

Symptoms:

When accessing the Site Recovery Plug-in from vCenter, the following error is displayed:

• "Site Recovery Manager - UI error: Unknown error. The latest version of Site Recovery UI is not available. Some functionality might be limited"



Environment

• VMware Live Site Recovery Manager 8.x
• VMware Live Site Recovery Manager 9.x
• VMware vSphere Replication 8.x
• VMware vSphere Replication 9.x
• VMware vCenter Server 7.x
• VMware vCenter Server 8.x

Cause

• The certificate in the SRM VAMI is assigned to a short name/incorrect FQDN that does not match the actual host name.
• In var/log/vmware/dr-client-plugin/drplugin.log  below events will be seen.

2025-12-04 09:11:45,521 [srm-reactive-thread-123] INFO  com.vmware.dr.plugin.handlers.dashboard.SrmHealthStatusHandler dc7f970f-c362-4bf9-b03d-c8022dd46b2c  - Checking health using URL: https://srm-lxx-prod.xxxx.xxx.xxx.com:443/drserver
2025-12-04 09:11:45,535 [srm-reactive-thread-121] WARN  com.vmware.dr.plugin.utils.ConnectionUtils e9af732c-a754-4d23-96ca-366d3674ad22  - Problem occurred while checking connection to https://srm-lxx-prod.xxxx.xxx.xxx.com:5480/configure
java.io.IOException: HTTPS hostname wrong:  should be <srm-lxx-lxx-prod.xxxx.xxx.xxx.com>
        at java.base/sun.net.www.protocol.https.HttpsClient.checkURLSpoofing(Unknown Source)
        at java.base/sun.net.www.protocol.https.HttpsClient.afterConnect(Unknown Source)
        at java.base/sun.net.www.protocol.https.AbstractDelegateHttpsURLConnection.connect(Unknown Source)
        at java.base/sun.net.www.protocol.https.HttpsURLConnectionImpl.connect(Unknown Source)
        at com.vmware.dr.plugin.utils.ConnectionUtils.connect(ConnectionUtils.java:79)
        at com.vmware.dr.plugin.utils.ConnectionUtils.connect(ConnectionUtils.java:66)



• /opt/vmware/support/logs/dr-client-plugin/drplugin.log on the vLSR or vSphere Replication appliance will show similar errors regarding the NetBios or short name
• Checking health using URL: https://[shortname]:443/drserver
• Java.net.UnknownhostException: [shortname]

Resolution

• Regenerate the certificate with the correct FQDN via SRM VAMI and re-register SRM with vCenter to clear the alert.

Note : Make sure VC can resolve configured SRM, vSphere replication hostnames.
