Autonomous Edge L2VPN Tunnel Fails Due to IPsec Pre-Shared Key Mismatch

Products

• VMware NSX

Issue/Introduction

• The environment/infrastructure is experiencing an L2VPN outage.
• The L2VPN peer-to-peer tunnel between the local network and remote network is down.
• Firewalls may alert on a shared secret (Pre-Shared Key) mismatch between the two gateways.
• The Autonomous Edge UI reports the L2VPN session Status is DOWN.


Environment

Autonomous NSX Edge

Cause

The IPsec Pre-Shared Key (PSK) between the managed NSX L2 VPN Server and the Autonomous Edge L2 VPN Client is mismatched. This prevents IKE Phase 1 negotiation from completing successfully, causing the underlying IPsec session and L2VPN tunnel to fail authentication.

Resolution

• Log in to the remote managed NSX Manager with admin privileges and navigate to Networking > VPN > L2 VPN Sessions.
• Retrieve the peer_code from the downloaded configuration file.
  • Download the Remote Side L2 VPN Configuration File
• Log in to the local Autonomous Edge web UI and paste the updated peer_code into the session configuration to synchronize the IPsec parameters.

Additional Information

• Add an Autonomous Edge as an L2 VPN Client
• Troubleshooting NSX IPSEC VPN
