ERROR: Component nsx-lcp-bundle cannot be found in depot when checking the compliance for the image in the vCenter.

Products

• VMware vCenter Server

Issue/Introduction

• The host status is currently displayed as 'Unknown' and triggers the following error during a cluster image compliance check:



• In vmware-vum-server.log, there is entry in the component and solution as well. In solutions, it is the latest version that is being used, in component it will be the old version.



  {
  -->     "add_on": null,
  -->     "alternative_images": null,
  -->     "base_image": {
  -->         "version": "8.0.3-0.79.24859861"
  -->     },
  -->     "components": {
  -->         "nsx-lcp-bundle": "4.2.1.3.0-8.0.24533885",
  -->     },
  -->     "solutions": {
  -->         "com.vmware.nsxt": {
  -->             "components": [
  -->                 {
  -->                     "component": "nsx-lcp-bundle"
  -->                 }
  -->             ],
  -->             "version": "4.2.3.3.0-25171319"
  -->         },


Environment

VMware vCenter Server 8.x

Cause

This issue typically occurs because certain components were inadvertently reclassified as user-managed components during the deployment of a new solution. In this specific instance, the issue impacted the NSX bundle configurations.

Resolution

The component needs to be removed from the desired image. Below are the steps:

1. Get the desired image of the cluster and check nsx-lcp-bundle in the component section:

   dcli com vmware esx settings clusters software get --cluster <cluster moid>

2. Create the draft:

   dcli com vmware esx settings clusters software drafts create --cluster <moid>

   The output is the draft id

3. Delete the component:

   dcli com vmware esx settings clusters software drafts software components delete --cluster <cluster moid> --draft <draft id> --component nsx-lcp-bundle

4. Commit the draft:

   dcli com vmware esx settings clusters software drafts software commit-task --cluster <cluster moid> --draft <draft id>
The output is commit task id

5. Monitor the commit task:

   dcli com vmware cis tasks get --task <task id>

6. Once the commit task has finished successfully, verify the desired image to ensure the offending component has been removed.

   dcli com vmware esx settings clusters software get --cluster <cluster moid>

7. On vCenter UI, will see compliance check succeeds.
