Aria Automation Orchestrator workflow fails with the LDAPException and resultCode 91

Products

• VMware Aria Suite

Issue/Introduction

Symptoms:

• Aria Automation Orchestrator workflow that uses AD plugin, fails with the below LDAPException in the workflow run log :
  LDAP Server returned error:An error occurred while attempting to connect to server <Active Directory Domain>:636: IOException(LDAPException(resultCode=91 (connect error), errorMessage='Unable to establish a connection to server  <Active Directory Domain>/<IP>:636 within the configured timeout of 20 milliseconds.', ldapSDKVersion=4.0.14, revision=<UUID>))
• The domain has multiple domain controllers.

Environment

Aria Automation Orchestrator 8.x

Cause

The LDAPException with resultCode 91 indicates that the LDAP client in the Orchestrator was unable to connect to the directory server.  This could be due various reasons :

• The domain controller, the Aria Automation Orchestrator is trying to connect might be temporarily unavailable.
• The domain controller resolved by the DNS server is demoted or unavailable in the environment.
• The Aria Automation Orchestrator is timing out while waiting for the response from the Active Directory server.

Resolution

To resolve the issue correct the underlying network issue that's resulting in the network timeout when Aria Automation Orchestrator tries to connect with Active Directory domain controller.

To workaround the issue :

• We can increase the maximum time to wait for the connection establishment from the default 20 milliseconds to a higher value by running Update an Active Directory server workflow from Aria Automation Orchestrator and update the timeout from the Advanced tab. Refer documentation Configuring the Active Directory Plug-In
• If the issue persist even after increasing the wait time, implement the client side load balancing such as Round Robin or Failover method by following the documentation Client-Side Load Balancing for the Active Directory Plug-In
