Insufficient IO activity for analysis

Products

• VMware vSAN
• VCF Operations

Issue/Introduction

This diagnostic finding is shown on the UI because the cluster seems to be idle.

Environment

VCF Operations 9.0

VSAN 9.0

Cause

The diagnostic engine classifies a cluster as idle if the average IOPS serviced during the selected time period is < 100. Running scans on idle vSAN clusters will generate inconclusive results.



The diagnostic finding will show two charts - one each for read and write IOPS on the cluster.

Resolution

If you want to run a troubleshooting type of scan, make sure the VMs on the cluster are powered on and are running IOs actively. If you want to run a benchmarking type of scan, please check the configuration of your benchmarking tool to ensure it’s configured to generate sufficient IOPS.

Additional Information

If you are using HCIBench for benchmarking your cluster, please refer to the HCIBench configuration guide here.
