Stacked Bars report shows only 5 metrics out of 5+n metrics

Products

• VMware Smart Assurance

Issue/Introduction

In MnR, when a stacked bars report is created, by default, only the 5 metrics out of 5+n are selected and shown. All of the others need to be selected in the user interface and clicks apply to show.

But when exporting to PDF, it reverts back to 5 metrics as seen below:

Environment

MnR 7.X

Resolution

Follow these steps to resolve:

• Login to the Frontend host
• Navigate to this directory:

  opt/APG/Web-Servers/Tomcat/Default/conf/

• Edit the module.properties file and add this line and save it:

  stk.maxsec=50

• Navigate to:

  opt/APG/bin

• Edit the file apg.properties and add this line and save it:

  stk.maxsec=50

• On the same directory run this command:

  ./manage-modules.sh service update tomcat

• Then run

  ./manage-modules.sh service start tomcat
