Probes not starting after disabling TLS 1.0 on Primary Hub

Products

• DX Unified Infrastructure Management (Nimsoft / UIM)
• DX Unified Infrastructure Management (Nimsoft / UIM)

Issue/Introduction

Probes not starting after disable the TLS 1.0 on Primary Hub

TLS 1.2 was then configured using

Support for TLS v1.2 (Microsoft SQL Server)

Environment

Release : 20.3.x or later

Database :MSSQL 2014

Resolution

Make the following changes to the data_engine configuration -
Change the Source in the data_engine config to the Fully Qualified Domain Name of the database xxxxxx,1433
(This should match the name in the SSL certificate)

Uncheck (disable) Always Trust Server Certificate in data_engine.cfg or IM GUI
TrustServerCertificate = false

so that it would use the configured jks store

After setting this restart the data_engine and check if connecting and processing.
Restart the Primary  robot and check if the probes connecting  to database
