Delete Available Interface via Odata

Products

• CA Network Flow Analysis (NetQos / NFA)

Issue/Introduction

How to Delete Available Interface using Odata API

Environment

Release : 10.0

Component : NQRAHV - NETQOS RA HARVESTER

Cause

Delete Interface

Resolution

Deleting one interface, see NFA guide:

https://techdocs.broadcom.com/us/en/ca-enterprise-software/it-operations-management/network-flow-analysis/23-3/reference/network-flow-analysis-odata-api/entity-operations/routers-and-interfaces/interfaces.html#concept.dita_2f14b01401eafd18084d4014b8ac51a7808d110d_DeleteInterfaceSingle



Interface 11 as example:





#Get router ID from management IP (GET)  (replace xxx.xxx.xxx.xxx with the correct IP address)

http://NFA:8981/odata/api/routers?$select=ID&$filter=((contains(routerAddress,'xxx.xxx.xxx.xxx')))

<d:ID m:type="Int32">1500555</d:ID>



#Get ID interfaces on the router based on router ID from previous query (GET)

http://NFA:8981/odata/api/interfaces?$select=ID,Name&$filter=(RouterId eq 1500555)&$format=json

Name "Interface 11"
ID 2112

List interface using RestClient:

http://NFA:8981/odata/api/interfaces(2112)



Delete interface using RestClient and using Method POST

http://NFA:8981/odata/api/interfaces/com.ca.nfa.odata.deleteInterfaces





We can see that the Interface 11 was removed on NetOps Portal/NFA web page and on NFA Interfaces.
